BACE Vertical Baler V32

SKU: v32-551

Our standard high density baler has an economical yet dependable design. This model is ideal for Retailers, Grocery Stores, Drug Stores, and other organizations that recycle OCC or Plastic Film.

Available Options
  • Full Bale Light,Oil Heater,Weather Proof Package

Lead Time: 2-4 weeks

Discounts Available – Call Now!

BUY NOW



Our standard high density baler has an economical yet dependable design. This model is ideal for Retailers, Grocery Stores, Drug Stores, and other organizations that recycle OCC or Plastic Film.

  • Ideal for: Big Box Retailers, Commissaries, Distribution Centers, Grocery Stores, Home Retailers, Hospitals, National Accounts, Pharmacies, Recyclers, Schools, Universities, Warehouses

Additional information

Color/Finish
  • Maroon
  • Royal Blue
  • Black
  • Forest Green
  • White
  • Bright Cyan
  • Bright Red
  • Brown
  • Dark Gray
  • Orange
  • Peach
  • Sea Green
  • Sky Blue
  • Slate Gray

Download all the specifications for this product.

DOWNLOAD PDF

Reviews

There are no reviews yet.

Be the first to review “BACE Vertical Baler V32”

Your email address will not be published. Required fields are marked *

Performance Specs

Description Value
Nominal Bale Size 36″ x 24″ x 30″
Bale Weight Up to 250 lbs
Bale Volume 15 cu. ft.
No. of Bale Tie Slots 4
Compact Force lbs – Normal / Maximum 12,016
Average Cycle Time 35 Seconds
Loading Height 35″
Ejector System Semi-Automatic
Full Bale Switch Optional



Hydraulic / Electrical Specs

Description Value
Motor HP 3 HP
Voltage 3 Phase 208V, 230V, 480V
Full Load Amps (A=Amps) 11A, 10A, 5A
Pump GPM 2.8
Normal System Pressure PSI 1700
Cylinder Bore x Stroke 3″ x 32″
Hydraulic Tank-Capacity Gallons 10 gal
Additional hydraulic/electrical configurations are available. Please contact BACE for more information.
